RELAY OVERLOAD ADVANCED 3PH 20 CLASS 3-12A SETTING 24VDC

SCH-LUCD12BL MFG #: LUCD12BL
  • Amperage: 3-12
  • Best Seller: No
  • Country Origin: FR
  • Dangerous Goods: No
  • Device Type: Overload Relay
  • Discontinued: No
  • Featured Product: No
  • Green Product: No
  • Limited Quantity: No
  • Made in Canada: No
  • Manufacturer: SCHNEIDER ELECTRIC
  • Manufacturer Category: TE1U-30355
  • Mfr Vendor ID: 599
  • Oversize product: No
  • Phase: 3
  • Restricted Delivery: No
  • SPF Product ID: 142085
  • Unit of Measure: E
  • UPC: 785901269601
  • Voltage: 24VDC
  • Web Group: 1020901000000
TeSys U control and diagnostic unit to be inserted in advanced power bases LUB120, LUB320, LUB380 to form a TeSys U starter controller, for 3-phase motor applications up to 5.5kW@400V. It provides full protection to motors with a rated current Ir 3-12A (Ir adjustable), overload tripping class 20, short circuit at 13 x Irmax, overcurrent at 14.2 x Ir, phase loss, insulation fault (protection of equipment only). It provides a thermal overload alarm to be used locally using a LUFDA module or remotely using a LULC module, and a test push button for overload simulation. To be used with a 24V DC voltage for the control of the starter (through the control terminals A1/A2 located in the power base). Certified when used in conjunction with a LUB power base (IEC, UL, CSA, CCC, EAC, Marine), Green Premium compliant (RoHS/REACh).
